Description
|
Rated load |
|
|
|
Radius of motion |
750mm |
|
|
Structural form |
Series connection |
|
|
Number of axles |
6 |
|
|
Repeatability |
±0.05mm |
|
|
Maximum working range |
First axis |
± 165° |
|
Second axis |
+88°/-70° |
|
|
Third axis |
+75°/-80° |
|
|
Fourth axis |
± 175° |
|
|
Fifth axis |
+30°/-215° |
|
|
Sixth axis |
±360° |
|
|
Maximum speed |
First axis |
148°/sec |
|
Second axis |
148°/sec |
|
|
Third axis |
222°/sec |
|
|
Fourth axis |
222°/sec |
|
|
Fifth axis |
222°/sec |
|
|
Sixth axis |
360°/sec |
|
|
Body weight |
≈80.5kg |
|
|
Installation method |
Floor mounting, bracket mounting, inverted mounting |
|
|
Ambient temperature |
5°C～45°C |
|
